Taitan TT-8001 Digital Airjet Weaving Platform

TT-8001 Digital Airjet Weaving Platform 190 cm high-speed airjet looms with up to 1300 RPM performance, equipped with Crank & Electronic Dobby systems for precision woven fabric manufacturing.

Quality Highlights

The TT-8001 platform operates at up to 1300 RPM across a 190 cm weaving width, combining ROJ Super Elf G2 yarn feeders, Changfang Electronic Dobby shedding, and Feisha digital loom controls to deliver consistent fabric quality across polyester, viscose, and blended woven programs.

Construction consistency

190 cm weaving width with precision reed system ensuring uniform warp spacing and stable beating across every pick. Available in 72, 84, 96, and 108 reed options to suit diverse fabric constructions, densities, and quality requirements.

Flexible weaving capability

Crank and electronic dobby systems allow both standard and structured weave designs.

Controlled yarn feeding

Electronic feeders from ROJ ensure stable yarn supply and tension control.

On-loom monitoring

Electronic sensors detect weft insertion faults and stop the machine to prevent defects.

Batch wise planning

Production is aligned with order quantity, approved construction, and dispatch schedules.

What to Share for Feasibility Confirmation

Sharing the details below helps confirm feasibility and production planning faster. If you have a reference image or design file, attach it when contacting sales.

Frequently Asked Questions

What are the key technical specifications of the TT-8001 Digital Airjet platform?
The TT-8001 Digital Airjet platform is configured with a 190 cm weaving width and delivers operating speeds up to approximately 1300 RPM. It combines high-speed airjet weft insertion, precision reed components, and digital loom controls for stable continuous woven fabric production.
How does the weft insertion and yarn feeding system work?
The platform uses a precision airjet insertion system where compressed air propels the weft yarn through the warp shed using main and relay nozzles. ROJ Super Elf G2 electronic weft feeders regulate yarn tension and feeding accuracy, supporting smooth insertion during high-speed weaving cycles.
What shedding systems are used and what weaving flexibility do they offer?
The machine is equipped with both Crank and Electronic Dobby shedding systems. The crank mechanism supports stable plain and standard weave constructions, while the Changfang electronic dobby enables independent heald frame control for twill, satin, and structured woven fabric developments.
How is the machine controlled and monitored during production?
The TT-8001 platform uses a Feisha digital loom control system that allows operators to start or stop the machine, adjust weaving parameters, monitor performance, and respond to system alerts. Electronic weft monitoring sensors automatically stop the loom if insertion faults occur, helping reduce defects.
What fabrics can be produced and how is production managed?
The platform supports manufacturing of plain, twill, and satin woven fabrics in polyester, viscose, polyester-viscose blends, and other apparel or home textile qualities. Production is managed on a make-to-order basis according to buyer-approved construction, GSM, width, quantity, and dispatch schedules.
